Distal Biceps Tendon Percutaneous Tenotomy

From WikiSM


Other Names

Anatomy of the cubital fossa. Note the relationship between the distal biceps tendon, bursa, and the adjacent neurovascular structures.[1]
  • Distal Biceps Tendon Needle Tenotomy
  • Distal Biceps Tendon Percutaneous Tenotomy

Background

Key Points

  • Percutaneous needle tenotomy involves repeatedly fenestrating the diseased tendon under ultrasound with the goal of promoting a healing response
  • An 18-20 gauge 1.5 inch needle is ideal for the procedure
  • Long axis, in plane technique is recommended
  • Identify the regional neurovascular structures during pre-procedural ultrasound
  • Be sure to council the patient on increased pain following the procedure

Anatomy

Palpation vs Ultrasound Guidance

  • To date, there are no studies comparing ultrasound-guided and palpation-guided approaches
  • We highly encourage you to perform this procedure with ultrasound guidance

Indications

Contraindications

  • Absolute
    • Anaphylaxis to injectates
    • Overlying cellulitis, skin lesion or systemic infection
  • Relative
    • Can be treated with less invasive means
    • Tendon tear or rupture
    • Hyperglycemia or poorly controlled diabetes
    • Lack of symptom improvement with previous injection

Procedure

Patient positioning for anterior approach. Note transducer is in long axis with needle in plane.[1]
A) shows the short axis view of the biceps tendon and its relationship to the neurovascular structures. B) shows the view in long axis with an arrow representing the needle trajectory[1]
Anterior approach showing a distal to proximal needle trajectory[2]
Patient positioning for the posterior approach.[1]
Ultrasound view of the posterior approach with the arrow representing the needle trajectory[1]

Equipment

  • Sterile prep (including chloraprep, chlorhexadine, iodine, etc)
  • Ultrasound with sterile probe cover
  • Gloves
  • Needle
    • Local anesthesia: typically 21-25 gauge, 1.5 inch
    • Tenotomy: 18-20 gauge, 1.5 to 3 inch needle
  • Syringe: 5-10 mL
  • Gauze
  • Ethyl Chloride
  • Bandage
  • Injectate
    • Local anesthetic
    • Corticosteroid/ injectate

Ultrasound Findings

  • Transducer: High Frequency, Linear
  • Identify
    • Distal biceps tendon
    • Proximal neurovscular structures
  • View
    • Anterior view great for short- and long-axis views but doesnt visualize most distal aspect of tendon well
    • Posterior view is best procedurally but provides limited diagnostic utility
    • Lateral and medial approaches provide excellent diagnostic information but are more limited procedurally because neurovascular structures are in the needle trajectory[3][4]
  • Common ultrasound findings for tendon:
    • Typical for tendinosis (hypoechogenicity, focal thickening, calcification, neovascularity, etc).
    • Important to distinguish from rupture as that would more likely benefit from surgical consultation

Technique: Long Axis, In-Plane

  • Patient Position
    • Supine
    • Arm extended at elbow, forearm supinated (see picture)
  • Probe Position, Needle Orientation
    • Long axis to the distal biceps tendon
    • Needle in plane, proximal to distal
  • Target
    • Distal biceps tendon
  • Pearls and Pitfalls
    • Safety and efficacy of procedure are poorly described
    • Identify neurovascular structures before you start
    • Anisotropy is common, use ample gel and consider a heel-toe maneuver
    • If you can not identify a safe path to the tendon, recommend posterior approach

Technique: Short Axis, In-Plane

  • Patient Position
    • Supine
    • Arm flexed at elbow, forearm hyperpronated (see picture)
  • Probe Position, Needle Orientation
    • Short axis to the distal biceps tendon
    • Needle in plane, radial to ulnar
  • Target
    • Distal biceps tendon
  • Pearls and Pitfalls
    • Safety and efficacy of procedure are poorly described
    • Posterior approach offers safest window to tendon but with less visualization
    • Identify the radial nerve during pre-procedural ultrasound

Aftercare

  • Council patient on increased pain immediately following the procedure

Complications

  • Skin: Subcutaneus fat atrophy, skin atrophy, skin depigmentation
  • Painful local reaction
  • Infection
  • Hyperglycmia
  • Nerve or blood vessel injury
  • Tendon rupture
    • Frequency unknown

See Also

References

  1. ↑ 1.0 1.1 1.2 1.3 1.4 Malanga, Gerard, and Kenneth Mautner. Atlas of ultrasound-guided musculoskeletal injections. McGraw-Hill, 2014.
  2. ↑ Sellon, Jacob L., Michael K. Wempe, and Jay Smith. "Sonographically guided distal biceps tendon injections: techniques and validation." Journal of Ultrasound in Medicine 33.8 (2014): 1461-1474.
  3. ↑ Kalume Brigido M, et al. Improved visualization of the radial insertion of the biceps tendon at ultrasound with a lateral approach. Eur Radiol. 2009;19(7):1817–1821
  4. ↑ Smith J, et al. Sonographic evaluation of the distal biceps tendon using a medial approach: the pronator window. J Ultrasound Med. 2010;29(5):861–865.
